Herb Adams Mod???

Just wanted to ask about the theory behind this spring perch mod.
What are the benefits and how is it done? Any help is much appreciated as I'm going to throw around 900hp through these split monos and will need all the help I can get!

Also, is there any upgrades to those little J-clips or is there none really needed?
nitrobully is offline   Reply With Quote
Old 10-15-2008, 08:05:12 PM   #2
79Zed28
Gold Member

79Zed28's Avatar

Join Date: Sep 2006
Location: Phoenix, AZ
Posts: 281
the search button is ur friend, many other posts on the topic
79Zed28 is offline   Reply With Quote
Old 10-15-2008, 09:03:58 PM   #3
aero80
Veteran Member

Join Date: Jul 2003
Location: SoCal
Posts: 1,192
If you mean raising the spring mount by .750" by drilling the eye-bolt holes higher up, then the main benefit is anti-squat increase, with the secondary benefit of lowering the car slightly.

Whether it works or not, depends upon a few other variables, including the length of the rear shackles, and the durometer of the front spring-eye bushings if you are running rubber.

Sounds like you're into straight-line? Not a lot of worthwhile result on the strip, when other solutions are much more modern and scienced-out.

I wondered about those J-clips too...
... but, I ran a stock-chassis'd (with respect to spring-eye mods anyway) '77-1/2 Z28 with an aluminum 427 (a 1971 ZL-1 engine) and a 4-gear, and I never had any problems with the rear spring eye mounts.
... same with my '80 canyon car, 496/540 motors, 4-gear, never a problem with the eye mounts.

EXCEPT: the strange moving wheelbase phenomenon... under extreme conditions, a rear wheel might move back in the wheelwell, leaving no marks on the spring where the perch might have sheared off the locating pin, or movement detectable in the front spring-eye perch area, nowhere else to check... very strange.
By exteme conditions, I do mean extreme. Leaving the track backwards at 140 mph over rough ground, or hitting a bump at high speed, stuff like that.

The best Adams mod, in my opinion, was always the front structure bars, bolt on and stiffened the car considerably.

The best I did it myself 'cause nobody makes a kit for it mod was always the doubling of the inner rocker panel. Take a rocker cut from a car in the yards, separate the inner floor panel along the entire length, then weld solidly to the floor and inner rocker, and cover back up with carpet. Nobody can see it, but oh man is the car ever stiffer.

2nd best mod in the same area (rear of car) was to reinforce the structure around the back window, and make sure that the window itself is well-sealed and attached. You'd be surprised how much our cars move around in this area.

For under a hundred bux you can increase the stiffness of your car by a huge amount.

I made my own subframe connectors which went from subframe rail to rear rail rather than to the spring-eye pocket.
Major improvement over the commercial traditional type offered for our cars.
Now Global West and maybe a few other companies offer this type of connection, but they are always weld-on at least on one end.
Mine were fully removable, great for frame alignment work on very high performance and often used at 100% cars.
The key is to place the bolts in all 3 axis locations... X, Y, Z.

With the above mods, my '80 T-top car could jack under the front subframe and lift both wheels on the side with no bending... that means even on the single support of the jack pad, the doors would open and close no prob, the T-tops could go on and off no prob, etc etc.

All this stuff makes for a HUGE improvement in road manners, and of course safety.


*** THE PROOF ***

In my fully stiffened '80 big-block T-top canyon car, I hit a coyote full-on at 125 MPH and suffered no damage to the car and the vehicle remained completely stable during the impact.
Well, there was a little biff mark on the corner of the rubber nose...

This is the car.
__________________
Aero80

Two Lane Blacktop style street and strip car:
Blueprinted 572, sequential port injection, forged everything, roller, Digi-6, SFI'd McLeod,TKO-600, cryo'd 1350s, Dana 60 w/ Detroit Truetrac, 12" 4WDB, adjustable coil-overs w/ Global West front, full adjustable rear, NHRA cage, Street Lights, 12:1 steerbox, baseball bats front and rear, solid body mounts, fiberglass hood.
aero80 is offline   Reply With Quote
